TUBING

Sizes

  • Outside Diameter

    26,7 mm - 339,7 mm 1.050" - 13,375"

  • Wall Thickness

    2,87 mm - 13,06 mm 0.113" - 0,514"

  • Length

    6,00 m - 18,30 m 19,68 ft - 60,04 ft

Production Standards & Material Qualities

• API 5CT certified for threaded and coupled tubing (According to API 5B)
• Full ERW grade range: H40, J55/K55, L80, N80, FBNAU, P110 and Q125
• Proprietary as rolled 80, 90 grade available
• Enhanced high collapse versions of L80 and P110 grades available

Tests & Certificates

• API 5CT
• Visual and dimensional inspection
• Mechanical Tests: Tensile, Flattening, Expanding
• Steady scarfing with 100% weldline ultrasonic testing
• Hydrotesting in place of 100%
• Consistent wall thickness with oversize drift options available
• Reduced tolerances through statistical process control
• Uniform concentricity, roundness, straightness and cylindricity
• Fully normalized weld zones
• NDT Standards: U/S (ASTM E 213 Level 3)
• Suitable for directional drilling and multiple fracturing operations
• Accredited lab tests and third party inpections available (full body and weld line UT, EMI, SEA)

Finishing Operations

• Plain end square cut or high quality API 5B certified threading and coupling
• Premium and semi-premium threads available
• High quality threaded compound, couplings and protectors
• Torque controlled coupling application
• External corrosion prevention with durable and environmentally safe coating
